COMPANY INTRODUCTION


Baoding Worth Engineering Technology Co., Ltd. founded in 2001 , Company is located in the Chinese ancient city --- Baoding. Our company has been engaged in producing custom made engineering accessories, OEM/ODM spare parts and industrial components for many years, including sand casting parts and investment casting spare parts, forging parts, sheet metal stamping spare parts, machined parts and plastic parts, which are widely used in petrochemical, automobile, chemical, environmental protection , machinery, construction, agriculture, aerospace, marine hardware and other industries.



THE PRECISION CASTING WE CAN MANAGE



Water glass casting: low temperature lost-wax casting process, with capacity to cast products range from 0.1kg to 100kgs. The usually used materials are carbon steel, alloy steel, and stainless steel, high manganese steel, special alloy steel, etc.

Silica sol casting/Invesment casting: medium temperature lost-wax casting process, with capacity to cast products range from 0.01kgs to 100kgs. The usually used materials are carbon steel, alloy steel, and stainless steel, high manganese steel, special alloy steel, etc.

Material:  Austenitic stainless steel: 201, 303,304,316,316L,1.4581,SCS14,SCS16

Hardening stainless steel:  17-4PH ,410,420, 440C

Weight:2-50KG

AccuracyClass CT5-CT7

Surface roughness up to R1.6-R6.3

Minimum thickness 2mm.

Tolerance Outer radius ≥0.3mm, inner fillet ≥0.5mm

Longest blind hole (diameter 10mm ) 30mm.

Machining: Turning,milling,drilling, boring, threading, grinding,CNC/NC machining and test facilities.

Heat treatment:  annealing, quenching, normalizing, carburizing.

Surface treatment: zinc coating, black oxide, black painting, powder painting, mirror polishing, satin polishing etc.

Standard applied: ASTM, ICI, BS, DIN, JIS.

Drawing software: Pro/E, Auto CAD, Solidworks, CAXA UG,CAD/CAM/CAE.
